V Grooving Machine Auto

The Codalam 20-Inch Auto V Grooving Machine is an electrically powered, automatic V-groove scoring machine built for packaging plants, box manufacturers, and album-cover producers running higher production volumes than a manual machine can comfortably handle. Like its manual counterpart, it cuts a precise V-shaped channel into cardboard, MDF, sunboard, foam board, and similar sheet materials — without cutting all the way through — so the board can be folded into a clean, sharp edge instead of a crushed or uneven bend.

V Grooving Machine Auto

Product Description

The Codalam 20-Inch Auto V Grooving Machine is an electrically powered, automatic V-groove scoring machine built for packaging plants, box manufacturers, and album-cover producers running higher production volumes than a manual machine can comfortably handle. Like its manual counterpart, it cuts a precise V-shaped channel into cardboard, MDF, sunboard, foam board, and similar sheet materials — without cutting all the way through — so the board can be folded into a clean, sharp edge instead of a crushed or uneven bend. Where the manual machine relies on a hand-fed lever for each groove, the automatic version drives the cutting action electrically, removing the manual feed step from the process and reducing operator fatigue and cut-to-cut variation across a long production run. This makes it better suited to commercial packaging plants, box manufacturers, and album-cover producers running batch after batch of the same fold-line specification. The machine cuts a groove up to 1mm in depth on a mild steel frame sized for 20-inch board widths. Typical applications mirror the manual model — fold lines for rigid gift boxes, sweet and dry-fruit boxes, wedding card boxes, cosmetic and promotional packaging, and album cover hinge lines — but at the throughput and consistency level needed for larger commercial production runs. Whether you operate a packaging plant, box manufacturing unit, or album production facility moving beyond manual-volume output, the Codalam 20-Inch Auto V Grooving Machine provides automated, repeatable V-groove scoring for higher-volume commercial use with less manual effort and more consistent output.

Key Features

  • Automatic Electric Operation
  • 20″ Machine Size
  • Groove Depth up to 1mm
  • Mild Steel Frame
  • Multi-Material Compatibility
  • Built for Higher-Volume Production
  • Reduced Cut-to-Cut Variation
  • Reduced Operator Fatigue
  • Consistent Commercial Throughput
  • Clean and Sharp Fold Edges
  • Versatile Packaging Applications
  • Album Cover Hinge-Line Compatibility

Technical Specifications

Ideal ForPackaging Plants, Box Manufacturers, and Album Production Units Running Higher Production Volumes.
OperationAutomatic Electric Feed and Grooving
ApplicationsPackaging and Box Fold Lines, Album Cover Hinge Lines, Commercial Carton Production
Machine Size20 Inches
Machine TypeAutomatic V-Groove Scoring Machine
Specification20″ Auto V Grooving Machine
Frame MaterialMild Steel
Automation GradeAutomatic (Electric)
Country of OriginMade in India
Max. Groove DepthUp to 1mm
Compatible MaterialsCardboard, Corrugated Board, MDF, Sunboard, Foam Sheet, Paperboard

Request pricing and availability

Send your application details and expected volume. We will share a suitable configuration and a quotation.
